DC CURRENT METER
MODEL NUMBER : DPM-41AD
Digital current meter to measure current consumption of any electrical equipment. 75mV shunt of various ratings can be used. The device is programmable for range of shunt used with soft keys provided on front of the panel. These settings are password protected.
| INPUT | 0 – 75mV |
| DISPLAY | 4 Digit 0.56” Seven Segment High Bright LED |
| POWER SUPPLY | 230 V AC ± 15 % |
| ACCURACY | Better than 0.5 % of full scale ± 1 Digit + Shunt Accuracy |
| ENCLOSURE SIZE (mm) | 96X96X65, 48X96X65 |
| AMBIENT TEMPERATURE | 0-60 °C |
| STORAGE TEMPERATURE | 0-70 °C |
| HUMIDITY | 0-95 % RH (non-condensing) |
