AC CURRENT METER
MODEL NUMBER : DPM-41AA
Digital current meter to measure current consumption of any electrical system or equipment. C.T. of any ratio or shunt can be connected to the device. C.T. ratio is programmable with soft keys provided on front of the panel. These settings are password protected. Instrument is designed to be used for any non-standard (programmable) C.T. ratio.
| INPUT | 0 – 5A AC True RMS or Average (Optional) |
| DISPLAY | 4 Digit 0.56” Seven Segment High Bright LED |
| C.T. RATIO | 1 TO 4000 (Linear) |
| DECIMAL POINT | Auto selection according to C.T. ratio |
| POWER SUPPLY | 230 V AC ± 15 % |
| ACCURACY | 0.5 % of full scale ± 1 Digit + C.T. Accuracy |
| ENCLOSURE SIZE (mm) | 96X96X65, 48X96X65 |
| AMBIENT TEMPERATURE | 0-60 °C |
| STORAGE TEMPERATURE | 0-70 °C |
| HUMIDITY | 0-95 % RH (non-condensing) |
